- Can be installed & operated horizontally and also vertically.
- The motors are designed to start at low voltage.
- Well-designed sleeve and tilting thrust bearings for longer life.
- Stator & Rotor are vacuum impregnated and coated properly with epoxy paint to ensure corrosion resistance & reduce eddy current losses.
- Copper rotor design.
- Motor OD is 196 mm.
- High operating efficiencies of the pump results in high water discharge and low power consumption.
- Rotors are dynamically balanced to ensure long bearing life and vibration free smooth operation.
- Pumps are provided with a reliable non-return valve to reduce water hammer & friction losses.
- 100% copper winding.
- Sleeve type coupling between motor and pump.
- Open type winding for motors for easy serviceability.
Salient Features
Technical Specifications
Power Rating Range
7.5 HP to 40 HP.
Head Range in Meters
24 Meters to 360 Meters
Discharge Range in LPM
1100 LPM to 200 LPM.
Working Voltage Range
300 Volts to 440 Volts.
Applications
- Agriculture & Irrigation schemes.
- Village water supply schemes.
- Community water Supply.
