- Teeth type/ gear/spline coupling between motor and pump.
- 100% copper winding.
- Tiffin box type pump design.
- Copper rotor design.
- SS impeller & SS bowl in fabrication design.
- Motor OD for V4: 96 mm.
- Motor OD for V5: 122 mm.
- 1.5 HP to 5 HP models have 4” motor.
- 6 HP & 7.5 HP models have 5” motor.
- The V5 motor in 6 HP & 7.5 HP provides better stability to the pump when installed at high depths thus increasing the life of the pump.
Salient Features
Technical Specifications
Power Rating Range
1.5 HP to 2 HP
Head Range in Meters
30 Meters to 137 Meters
Discharge Range in LPM
125 LPM to 20 LPM
Working Voltage Range
160 Volts to 240 Volts
Frequency
50 Hz
Type of Duty
S1
Power Rating Range
3 HP to 7.5 HP
Head Range in Meters
37 Meters to 300 Meters
Discharge Range in LPM
125 LPM to 20 LPM
Working Voltage Range
240 Volts to 440 Volts
Applications
- Residential
- Commercial
- Multistorey Buildings
- Agriculture & Irrigation Purpose.
- Drip & Sprinkler Systems.
